General Specs |
| Color | Stainless Steel |
| Color/Finish Name | PrintProof™ Stainless Steel |
| Door Color | PrintProof™ Stainless Steel |
| Fingerprint Resistant Finish | Yes |
| Type of Refrigerator | French Door Refrigerator |
| Installation Type | Freestanding |
| Depth Type | Standard Depth |
| Number of Doors | 4 |
| Total Capacity (cu. ft.) | 28.6 |
| Refrigerator Capacity (cu. ft.) | 17.0 |
| Freezer Capacity (cu. ft.) | 8.4 |
| Freezer Door Type | Pull Out Drawer |
| Defrost Type | Auto Defrost |
| Door Panel Type | Solid |
| Door Swing Option | Double Doors |
| Ice Maker Type | Dual Ice Maker |
| Ice Type | Full Size Cubes, Crushed Ice |
| Ice Maker | Yes |
| Ice Storage Capacity (lbs.) | 3.8 |
| Ice/Water Dispenser | Yes |
| Defrost System | Automatic |
| Refrigeration General Features | Digital Temperature Control, Door Alarm, Freezer Light, Interior Light, LED Light, Sabbath Mode, See-Thru Door, Self-Closing Door, Smart App Compatible, Wi-Fi Capable, Hidden Hinge |
| Refrigeration Dispenser Features | Water Dispenser, Water Filtration, Dispenser Location - External |
| Custom Panel Ready | No |
| Smart Compatible | Yes |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 35.75 |
| Depth (in.) | 34.38 |
| Depth Less Door (in.) | 30 |
| Depth Excluding Handles (in.) | 34.38 |
| Height (in.) | 70.25 |
| Height Without Door/Hinge (Case) (in.) | 68.88 |
| Overall Height (in.) | 70.25 |
| Shipping Depth (in.) | 36.38 |
| Shipping Width (in.) | 37.88 |
| Shipping Height (in.) | 72.38 |
| ENERGY STAR Certified | Yes |
| ADA Compliant | Yes |
| Manufacturer Warranty | 1 Year Parts & Labor/ 5 Year Compressor & Sealed System |
| Voltage | 115 |
Capacity |
| Freezer (cu.ft.) | ft³ 8.4000 |
| Refrigerator (cu.ft.) | ft³ 17.0000 |
Convenience |
| ADA Compliant | Yes |
| Auto Closing Door Hinge | Yes |
| Temperature Controls | Electronic/Digital |
Cooling |
| Refrigerant | Low GWP, Zero ODP and More Energy Efficient Refrigerant (R600a/84g/ 2.96oz) |
| Compressor Type | Smart Inverter Compressor |
| Evaporator | 1 |
| Fresh Air Filter | Yes |
| Temperature Sensors | 3 |
Dimensions/Clearances/Weights |
| Depth (Draw Open Fully without Handle) | in 55.3750 |
| Depth (to Hinge Cover) | in 30.0000 |
| Depth (Total with Door Open) | in 48.5000 |
| Depth without Door | in 30.0000 |
| Depth without Handles | in 34.3750 |
| Door Edge Clearance without Handle | in 2.2500 |
| Height to Top of Case | in 68.8750 |
| Height to Top of Door Hinge | in 70.2500 |
| Installation Clearance | Sides 1/8", Top 1", Back 2" |
| Weight (Unit/Carton) | TBD |
| Width (Door Fully Open without Handle) | in 56.7500 |
Energy |
| Energy Consumption (kWh/Year) | 785 |
Freezer |
| Divider | Yes |
| Door Type | Pull Drawer |
| Drawer Divider | No |
| Drawers/Shelves | 2-Tier Organization |
| Freezer Handle | Smart Pull™ Pocket Handle |
| Freezer Light | LED Lighting (Upper) |
Materials and Finishes |
| Insulation | Low GWP and Zero ODP Blowing Agent |
| All Available Colors | PrintProof™ Stainless Steel |
| Hidden Hinges | Yes |
Summary |
| Display Type | Smooth Touch Control / White LED |
Refrigerator ThinQ® Smart Features |
| SmartDiagnosis™ | Yes |
| ThinQ Care™ | Yes |
| Wi-Fi Enabled | Yes |
| ThinQ UP™ | Yes |
Temperature Range (°F) |
| Freezer | 41 / 37 / 33 / 29 / Freezer |
Water & Ice System |
| Freezer Ice Maker Ice Type | Cube |
| Daily Ice Production (lbs) | 3.0 / 3.3 (IcePlus) lbs |
| Dispenser Type | Ice & water |
| Ice Storage Capacity (lbs) | 3.8 lbs |
Full-Convert Drawer™ |
| Full-Convert Drawer™ Handle Type | Pocket Handle |
| Full-Convert Drawer™ Light | LED lighting |
| Full-Convert™ Drawer Capacity | ft³ 3.2000 |
