General Specs |
| Color | Stainless Steel |
| Color/Finish Name | PrintProof™ Stainless Steel |
| Door Color | PrintProof™ Stainless Steel |
| Handle Color | Stainless Steel |
| Fingerprint Resistant Finish | Yes |
| Type of Refrigerator | French Door Refrigerator |
| Installation Type | Freestanding |
| Depth Type | Standard Depth |
| Number of Doors | 3 |
| Total Capacity (cu. ft.) | 24.5 |
| Refrigerator Capacity (cu. ft.) | 16.3 |
| Freezer Capacity (cu. ft.) | 8.2 |
| Freezer Door Type | Pull Out Drawer |
| Door Panel Type | Solid |
| Door Swing Option | Double Doors |
| Ice Maker Type | Dual Ice Maker |
| Ice Type | Full Size Cubes, Crushed Ice |
| Ice Maker | Yes |
| Ice Storage Capacity (lbs.) | 7.4 |
| Ice/Water Dispenser | Yes |
| Dispenser Location | External |
| Refrigeration General Features | Child Lock, Digital Temperature Control, Wi-Fi Capable, Smart App Compatible, Door Alarm, Freezer Light, Hidden Hinge, Interior Light, LED Light, Sabbath Mode, Self-Closing Door |
| Refrigeration Dispenser Features | Water Filtration, Water Dispenser |
| Smart Compatible | Yes |
| Appliance Fit Width (in.) | 33 |
| Width (in.) | 32.94 |
| Depth (in.) | 35.94 |
| Depth w/Door Open 90 Degrees (in.) | 46.69 |
| Depth Less Door (in.) | 29.5 |
| Depth Excluding Handles (in.) | 33.44 |
| Depth Including Handles (in.) | 35.94 |
| Height (in.) | 69.94 |
| Height Without Door/Hinge (Case) (in.) | 68.63 |
| Overall Height (in.) | 69.94 |
| Shipping Depth (in.) | 37.63 |
| Shipping Width (in.) | 35.13 |
| Shipping Height (in.) | 71.44 |
| Product Weight (lbs.) | 262 |
| ENERGY STAR Certified | Yes |
| ADA Compliant | Yes |
| Manufacturer Warranty | 1 Year Parts & Labor / 5 Year Sealed System & Compressor Parts & Labor / 10 Year Compressor Parts & Labor |
| Voltage | 115 |
Capacity |
| Freezer (cu.ft.) | ft³ 8.2000 |
| Refrigerator (cu.ft.) | ft³ 16.3000 |
Convenience |
| ADA Compliant | Yes |
| Auto Closing Door Hinge | Yes |
| Temperature Controls | Electronic/Digital |
Cooling |
| Refrigerant | Low GWP, Zero ODP and More Energy Efficient Refrigerant (R600a / 70g / 2.47oz) |
| Compressor Type | Smart Inverter Compressor |
| Evaporator | 1 |
| Fresh Air Filter | Yes |
| Multi-Air Flow™ System | Yes |
| Temperature Sensors | 5 |
Dimensions/Clearances/Weights |
| Case Edge Clearance (Door Fully Open) | in 54.6870 |
| Depth (Draw Open Fully without Handle) | in 53.1870 |
| Depth (to Hinge Cover) | in 24.3120 |
| Depth (Total with Door Open) | in 46.6870 |
| Depth with Handles | in 35.9370 |
| Depth without Door | in 29.5000 |
| Depth without Handles | in 33.4370 |
| Dimensions (W case x H top of hinge x D with handles) | 32 15/16" x 69 15/16" x 35 15/16" |
| Door Edge Clearance with Handle | in 4.7500 |
| Door Edge Clearance without Handle | in 2.2500 |
| Height (Floor to Top of Drawer) | in 27.6250 |
| Height to Top of Case | in 68.6250 |
| Height to Top of Door Hinge | in 69.9370 |
| Installation Clearance | Sides 1/8", Top 1", Back 2" |
| Width (Door Fully Open without Handle) | in 50.8120 |
| Width (Door Open 90˚ with Handle) | in 41.6250 |
| Width (Door Open 90˚ without Handle) | in 36.6870 |
Energy |
| Energy Consumption (kWh/Year) | 710 |
Freezer |
| Door Type | Pull Drawer |
| Drawer Divider | Yes |
| Drawers/Shelves | 2-Tier Organization |
| Freezer Handle | Normal |
| Freezer Light | Upper (LED lighting) / Lower (Pocket) |
Materials and Finishes |
| Insulation | Low GWP and Zero ODP Blowing Agent |
| All Available Colors | PrintProof™ Stainless Steel |
| Hidden Hinges | Yes |
Refrigerator |
| Cool Guard | No |
| Crisper Bins | 2 |
| Door Bin Construction | Flat |
| Glide N’ Serve™ Drawer | Yes |
| Handle Type | New (Hybrid) |
| No. of Door Bins | 3 Left, 3 Right |
| No. of Shelves | 4 Split (4 Fixed) |
| Refrigerator Light | Yes |
| Shelf Construction | Spill protector Tempered glass |
Summary |
| Display Type | Membrane / White LED |
Refrigerator ThinQ® Smart Features |
| SmartDiagnosis™ | Yes |
| ThinQ Care™ | Yes |
| Wi-Fi Enabled | Yes |
| ThinQ UP™ | Yes |
Water & Ice System |
| Freezer Ice Maker Ice Type | Cubed |
| In-Door Ice Maker Ice Type | Cubed / Crushed |
| Freezer Ice Maker Daily Production | lb 2.5000 |
| Dispenser Light | No |
| Ice Storage Capacity (lbs) | 2.3 lbs + 5.1 lbs |
| Ice System | IcePlus™ |
| IcePlus™ Production (lbs) | lb 5.5000 |
| Water Filter | LT1000P |
| Water Filtration System | 1 Stage |
