General Specs |
| Color | Black |
| Color/Finish Name | Black |
| Door Color | Black |
| Handle Color | Black |
| Dishwasher Type | Standard |
| Number of Cycles | 3 |
| Control Panel Type | Top |
| Tub Material | Stainless Steel |
| Door Panel Type | Solid |
| Noise level (dB) | 47 |
| Sound Rating Range | Quieter |
| Dishwasher Features | Cutlery Holder, Door/Child Lock, Food Disposal, Sensor Wash |
| Third Rack | No |
| Sanitize Option | Yes |
| Water Softener | No |
| Delay Wash (Up to hours) | 12 |
| Number Of Place Settings | 8 |
| Smart Compatible | No |
| Appliance Fit Width (in.) | 18 |
| Width (in.) | 17.75 |
| Depth (in.) | 23.5 |
| Depth Excluding Handles (in.) | 22.5 |
| Depth Including Handles (in.) | 22.5 |
| Depth w/Door Open 90 Degrees (in.) | 45.63 |
| Height (in.) | 32.5 |
| Product Weight (lbs.) | 72 |
| Cut Out Width (in.) | 18 |
| Cut Out Depth (in.) | 22.5 |
| Cut Out Height (in.) | 32.5 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| ENERGY STAR Certified | Yes |
| ADA Compliant | Yes |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 8.9 |
Features |
| Door Liner | Stainless Steel |
| Control Type | 4 Pushbuttons
Fully Integrated Electronic
Top Controls |
| Dishwasher Control Features | 3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators
Audible End-of-Cycle Signal
Cycle Countdown
Last Cycle Memory
Start/Reset Pad |
| Wash System | 3-Level
Standard |
| Wash System Features | Automatic HotStart
Automatic Temperature Control
Dual Pump
Flood Control System
Piranha™ Hard Food Disposer |
| Sensor | Clean Sensor |
| Wash Arms | 2 with Upper Nozzle |
| Water Filtration System | 3-Stage Manual Clean Filtration |
| Dispenser | Rinse Aid with Indicator and Adjustment |
| Dishwasher Cycles | Auto Sense
Heavy Wash
Light Wash |
| Number of Options | 5 |
| Dishwasher Options | Child Lock
Delay Start 1-12 Hr.
Sani (NSF 184 Certified)
Start/Reset
TempBoost |
| Rack Features | 1 Piece Mid Silverware Basket w/ 1 Cell Cover
1 Plastic Utility Shelf - Upper
Ball-Tipped Tines
Fold-Down Tines - Lower
Stem Safe |
| Racking System | Gray |
| Upper Rack | 1 Rack handle
Adjustable
Nylon |
| Lower Rack | 1 Rack handle
Nylon |
| Dishwasher Drying Features | Condensate Dry |
| Leveling System | Leveling Legs |
| Latch | Center Pull |
| WiFi Connect | Optional (Requires part no. PBX10W00Y0) |
| Connected Capabilities | Amazon Alexa
IFTTT
The Google Assistant |
| Exterior Style | 18" Wide |
Appearance |
| Door Style | Full-Length Flat Door |
| Handle | Pocket Handle |
| Handle Color | Color-Matched |
| Handle Design | Recessed |
Economical/Quiet |
| Motor Type | Single Speed |
| Outer Wrap | U-Blanket |
| Door Insulation | Insulation
Mastic |
Weights and Dimensions |
| Cabinet Width | 18 in |
| Height w/ Legs Retracted - Minimum Height | 32 1/2 in |
| Height w/Legs Extended - Maximum Height | 34 5/8 in |
Power/Ratings |
| Calrod Heater Watts | 1100 |
