General Specs |
| Color | Stainless Steel |
| Color/Finish Name | PrintProof™ Stainless Steel |
| Door Color | PrintProof™ Stainless Steel |
| Handle Color | Stainless Steel |
| Fingerprint Resistant Finish | No |
| Type of Refrigerator | French Door Refrigerator |
| Installation Type | Freestanding |
| Depth Type | Counter Depth |
| Number of Doors | 4 |
| Total Capacity (cu. ft.) | 25.5 |
| Refrigerator Capacity (cu. ft.) | 15.7 |
| Freezer Capacity (cu. ft.) | 7 |
| Freezer Door Type | Pull Out Drawer |
| Door Panel Type | Solid |
| Ice Maker Type | Single Ice Maker |
| Ice Maker | Yes |
| Ice Storage Capacity (lbs.) | 3.8 |
| Ice/Water Dispenser | Yes |
| Dispenser Location | Internal |
| Refrigeration General Features | Hidden Hinge, Sabbath Mode, Door Alarm, Digital Temperature Control, Smart App Compatible, Wi-Fi Capable, Self-Closing Door, LED Light, Interior Light, Freezer Light |
| Refrigeration Dispenser Features | Water Dispenser |
| Custom Panel Ready | No |
| Smart Compatible | Yes |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 35.75 |
| Depth (in.) | 32.25 |
| Depth Less Door (in.) | 25.38 |
| Depth Excluding Handles (in.) | 29.75 |
| Depth Including Handles (in.) | 32.25 |
| Height (in.) | 70.25 |
| Height Without Door/Hinge (Case) (in.) | 68.88 |
| Overall Height (in.) | 70.25 |
| Shipping Depth (in.) | 35.13 |
| Shipping Width (in.) | 37.88 |
| Shipping Height (in.) | 72.38 |
| Product Weight (lbs.) | 273 |
| ENERGY STAR Certified | Yes |
| ADA Compliant | Yes |
| Manufacturer Warranty | 1 Year Parts & Labor/5 Year Sealed System & Compressor |
| Voltage | 115/120 |
Capacity |
| Freezer (cu.ft.) | ft³ 7.0000 |
| Refrigerator (cu.ft.) | ft³ 15.7000 |
Convenience |
| ADA Compliant | Yes |
| Auto Closing Door Hinge | Yes |
| Temperature Controls | Electronic/Digital |
Cooling |
| Refrigerant | Low GWP, Zero ODP and More Energy Efficient Refrigerant (R600a/84g/ 2.96oz) |
| Compressor Type | Smart Inverter Compressor |
| Evaporator | 1 |
| Temperature Sensors | 3 |
Dimensions/Clearances/Weights |
| Case Edge Clearance (Door Fully Open) | in 21.0000 |
| Depth (Draw Open Fully without Handle) | in 49.5000 |
| Depth (to Hinge Cover) | in 18.8750 |
| Depth (Total with Door Open) | in 42.5000 |
| Depth without Door | in 25.3750 |
| Depth without Handles | in 29.7500 |
| Door Edge Clearance without Handle | in 2.2500 |
| Height (Floor to Top of Drawer) | in 33.2500 |
| Height to Top of Case | in 68.8750 |
| Height to Top of Door Hinge | in 70.2500 |
| Installation Clearance | Sides 1/8", Top 1", Back 2" |
| Width (Door Fully Open without Handle) | in 56.7500 |
| Width (Door Open 90˚ without Handle) | in 40.2500 |
Energy |
| Energy Consumption (kWh/Year) | 663 |
Freezer |
| Divider | Yes |
| Door Type | Pull Drawer |
| Drawer Divider | No |
| Drawers/Shelves | 2-Tier Organization |
| Freezer Handle | Smart Pull™ Handle (Pocket Handle) |
| Freezer Light | LED Lighting (Upper) |
| Shelf Construction | Spill Protector Tempered Glass |
Materials and Finishes |
| Insulation | Low GWP and Zero ODP Blowing Agent |
| All Available Colors | PrintProof™ Stainless Steel |
| Hidden Hinges | Yes |
Refrigerator |
| Cool Guard | Yes |
| Handle Type | Vista |
| No. of Door Bins | 3 Left, 3 Right |
| Refrigerator Light | Yes |
Summary |
| Display Type | Smooth Touch Control / White LED |
Refrigerator ThinQ® Smart Features |
| SmartDiagnosis™ | Yes |
| ThinQ Care™ | Yes |
| Wi-Fi Enabled | Yes |
| ThinQ UP™ | Yes |
Temperature Range (°F) |
| Freezer | 41/37/33/29/Freezer |
Water & Ice System |
| Freezer Ice Maker Ice Type | Cubed |
| Daily Ice Production (lbs) | 2.5/2.7 (Ice Plus) lbs |
| Dispenser Type | Internal Water Only |
| Ice Storage Capacity (lbs) | 3.8 lbs |
Full-Convert Drawer™ |
| Full-Convert Drawer™ Handle Type | Pocket Handle |
| Full-Convert Drawer™ Light | LED lighting |
| Full-Convert™ Drawer Capacity | ft³ 2.8000 |
