General Specs |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Fuel Type | Natural Gas |
| Burner Type | Sealed |
| Number of Elements/Burners | 5 |
| Cooktop Surface | Stainless Steel |
| Cooktop Surface Style | Burner Grate |
| Ignition Type | Spark |
| Grate Material | Cast Iron |
| Cooktop Features | Continuous Grate, Dual Element, LP Convertible |
| Propane Convertible | Yes |
| Downdraft Ventilation | No |
| Outdoor Approved | Yes |
| Commercial Use Approved | No |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 36 |
| Depth (in.) | 21 |
| Height (in.) | 3.69 |
| Cut Out Width (in.) | 35.63 |
| Cut Out Depth (in.) | 20 |
| Cut Out Height (in.) | 5.25 |
| ADA Compliant | Yes |
| Made In The USA | Yes |
| Made In | USA |
| Manufacturer Warranty | 1 Year Limited Parts and Labor |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 15 |
Certifications |
| ADA Compliant | ADA Height and Side Reach Compliant |
| UL | Yes |
Exterior Details |
| Knob Color | Stainless Steel |
| Knob Type | Metal |
Cooktop Details |
| Combination Match with Oven | KOES527P, KOES530P, KOSC104FSS, KOSC504, KOSE500, KOSE507, KOSE900, KOST100, KOST107 |
| Cooktop Surface Color | Color Coordinated |
| Cooktop Surface Material | Stainless Steel |
| Griddle Included | Optional Accessory |
| Heating Element On Indicator Light | No |
| Hot Surface Indicator Light | No |
| Ignition Type | Direct Spark Ignition |
| Installs Over Built-In Oven | Yes |
Dimensions |
| Common Size | 36 in |
| Cutout Depth Max | 20 in |
| Maximum Height | 4.56 in |
Controls |
| Control Location | Front |
| Control Type | Knobs |
Details |
| Cooktop Configuration | All Burners |
| Digital Display | No |
| Fuel Type | Gas |
| LP Convertible | Yes - Kit Included |
| Power Outage Compatible | Yes |
Element/Burner Details |
| Automatic Pan Detection | No |
| Automatic Pan Size Adjustment | No |
| Center Element Burner Power | 20,000 BTU |
| Center Element Burner Type | Even Heat Dual |
| Center Rear Element-Burner Power | 20,000 BTU |
| Center Rear Element-Burner Type | Professional Dual Tier |
| Cooktop Type | Standard |
| Left Front Element-Burner Power | 10000 BTU |
| Left Rear Element-Burner Power | 6,000 BTU |
| Left Rear Element-Burner Type | Simmer |
| Power Boost | No |
| Right Front Element-Burner Power | 10,000 BTU |
| Right Rear Element-Burner Power | 7,000 BTU |
Ventilation Details |
| Downdraft Vent | No |
Grate Details |
| Grate Details | Cast Iron Grates, Continuous, Dishwasher Safe, Matte Finish |
Electrical |
| Power Cord Included | Yes |
Features |
| Cooktop Features | 20K BTU Dual-Ring Burner, ADA Compliant, Cookshield Finish, Even-Heat Melt Burner |
