General Specs |
| Color | Stainless Steel |
| Color/Finish Name | Fingerprint Resistant Stainless Steel |
| Door Color | Fingerprint Resistant Stainless Steel |
| Handle Color | Fingerprint Resistant Stainless Steel |
| Fingerprint Resistant Finish | Yes |
| Type of Refrigerator | French Door Refrigerator |
| Installation Type | Freestanding |
| Depth Type | Standard Depth |
| Number of Doors | 3 |
| Total Capacity (cu. ft.) | 24.7 |
| Refrigerator Capacity (cu. ft.) | 17.44 |
| Freezer Capacity (cu. ft.) | 7.28 |
| Freezer Door Type | Pull Out Drawer |
| Defrost Type | Auto Defrost |
| Door Panel Type | Solid |
| Door Swing Option | Double Doors |
| Ice Maker Type | Single Ice Maker |
| Ice Type | Crushed Ice |
| Ice Maker | Yes |
| Ice/Water Dispenser | Yes |
| Dispenser Location | Internal |
| Defrost System | Automatic |
| Refrigeration General Features | Door Alarm, Freezer Light, LED Light, Interior Light |
| Refrigeration Dispenser Features | Dispenser Control Lock-Out, Water Dispenser, Water Filtration, Filtration Replacement Indicator Light |
| Custom Panel Ready | No |
| Garage Ready | No |
| Smart Compatible | No |
| Commercial Use Approved | No |
| Appliance Fit Width (in.) | 33 |
| Width (in.) | 32.75 |
| Depth (in.) | 37.5 |
| Depth w/Door Open 90 Degrees (in.) | 47.75 |
| Depth Less Door (in.) | 30.63 |
| Depth Excluding Handles (in.) | 35 |
| Depth Including Handles (in.) | 37.5 |
| Height (in.) | 69.88 |
| Height Without Door/Hinge (Case) (in.) | 68.63 |
| Overall Height (in.) | 69.88 |
| Product Weight (lbs.) | 253 |
| ENERGY STAR Certified | Yes |
| ADA Compliant | No |
| Manufacturer Warranty | 1 Year Limited Parts & Labor |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 15 |
Appearance |
| Case Color | Gray |
| Door Stops | Yes |
| Exterior Design | Contoured Crown Doors |
| Handle Design | Designer Style |
| Textured Steel Case | Case Only- Color Matched |
Economical / Quiet |
| Cabinet Liner | ABS |
Additional Features |
| Configuration | French Door Bottom Freezer |
| Control Type | Upfront Electronic Temperature Controls Digital Temperature Display |
| Defrost Type | Frost Guard |
| Dispenser | Internal Water |
| Door Liner | HIPS |
| Filter Location | Upper right corner |
| Freezer Cabinet Drawer Features | Freezer Drawer |
| Freezer Features | Interior Lighting - LED Ice Bucket |
| Freezer Storage Baskets | 2 Total 1 Full-Width, Full-Extension Plastic |
| Fresh Food Cabinet Drawers | Multi-Level Drawers 2 Humidity Controlled Drawers 1 Full-Width, Adjustable Temperature Drawer |
| Fresh Food Cabinet Shelves | 5 Total Glass 4 Split Adjustable 1 Quick Space Shelf |
| Fresh Food Door Bins | 8 Clear Look 6 Adjustable with Gallon Storage 2 Fixed |
| Interior Lighting - Dual Level LED | Interior Lighting - Dual Level LED |
| Icemaker | Factory-Installed |
| Leveling System | 2 Point Front Adjustable |
| OU Certified | OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately |
| Performance Features | Easily Removable Door Gaskets |
| Refrigerant Type | R600a |
| Sabbath Mode | Optional |
| Showroom Power Mode | For Demo Mode, Press and hold Alarm + Freezer + Turbo Cool buttons simultaneously for 3 seconds. Select options with the Fridge or Freezer buttons simultaneously. Enter Code 1 to select Demo Mode. Press the Alarm button. Cooling system will turn off |
| Temperature Display | Internal Digital |
| Temperature Management Features | Turbo Cool setting Multiflow Air System with Electronic Sensors |
| Tuckaway Shelf | Yes |
| Water Filtration | GE Water Filtration (XWFE Filter) Water Filter Indicator Light |
| WiFi Connect | Optional (Requires part no. PBX23W00Y1) |
Power / Ratings |
| Energy Consumption (kWh/year) | 609 |
| Watts | 294 |
Additional Dimensions |
| Back Air Clearances | 2 in |
| Height to Top of Case | 68.625 in |
| Height to Top of Hinge | 69.875 in |
| Side Air Clearances | 1/8 in |
| Top Air Clearances | 1 in |
| Width w/Door Open 90 Degrees Incl. Handle | 40.875 in |
